Two Head Stereo Cassette Deck (1974-78)
Description
Nakamichi Manuals HiFi Engine 500 Manual Nakamichi Av 500 Manual Right here, we have countless book nakamichi av 500 manual and collections to check out. We additionally allow variant types and along with type of the books to browse. The normal book, fiction, history, novel, scientific research, as without difficulty as various supplementary.
The Nakamichi 500 is the most advanced two-head cassette deck ever made.
At the heart of this outstanding system is Nakamichi's unique head, a technological breakthrough that closely approaches the performance capabilities of our world famous three had cassette decks.
Nakamichi Research Inc, whose meteoric rise to global renown stems from the new technology used to enhance the two Nakamichi three-head cassette deck Tri Tracer systems (1000 and 700), now takes pleasure in presenting a two-head cassette system which in every way echoes Tri Tracer originality and reliability.
The new Nakamichi 500 is of special significance because of newly-developed Focused-Gap type record/playback heads designed by Nakamichi to give a far better head-saturation level than is found in other two-head systems.
Consequently, the Dual Tracer's dynamic range is greatly extended, and in fact in terms of two-head cassette technology it offers a frequency response and signal-to-noise ratio that put it well out in front, even though it arrived late on the scene!
Specifications
Type: 2-head, single compact cassette deck
Track System: 4-track, 2-channel stereo
Tape Speed: 4.8 cm/s
Heads: 1 x record/playback, 1 x erase
Motor: DC servo
Tape Type: type I, CrO2
Noise Reduction: B
Frequency Response: 40Hz to 17kHz (Cr02 tape)
Signal to Noise Ratio: 63dB (dolby B)
Wow and Flutter: 0.13%
Total Harmonic Distortion: 1.5%
Input: 70mV (line), 0.2mV (mic)
Output: 1V (line)
Dimensions: 15 x 4.5 x 10 inches
Nakamichi Av-500 User Manual
Weight: 15.5lbs
Year: 1974
Downloads
brochure - Jeepo65
instruction/owners manual - aangen
service manual -
Related Catalogues
Nakamichi Av-500 Manual
If you have any problems opening files please read the download FAQ. All files are provided under strict licence and reproduction without prior permission or for financial gain is strictly prohibited.
If you have additional documentation please consider donating a copy to our free archive.
Nakamichi Cassette Decks
482
580
Reviews
Login or register to post reviews
Reviewed Jun 09th, 2017 by audionut69
Fantastic machine. Reason it is so hot is that the head material used is far more efficient magnetically. Ergo, it uses less recording equalization and can be driven harder (more of a signal can be recorded without overloading the tape) when recording . Conversely, on playback it needs less playback rolloff.
Negatively, tapes made on this machine must be played back on a Nak or it will sound like it is lacking in the high end. Conversely a tape made on another machine will have a rising high end on playback due to the different equalizations used.
Signal to noise ratio and dynamic range is awesome and the deck comes close to matching the best reel to reel decks out there..
Reviewed Mar 31st, 2012 by Palko
Nakamichi Av 500 User Manual
Superior 2 head unit
