Universal Docking Stations. Universal docking stations turn the USB port of computer into a docking station connector. A single USB cable to your computer docks your portable device to support multiple display outputs, audio, Ethernet and other USB peripherals. Designed exclusively for ultraslim HP EliteBook Notebook PCs, the HP UltraSlim Docking Station expands display, network, and device connectivity so you can be more productive throughout the day—all through a simple one-click slide-in side dock. Apr 22, 2021 The right laptop docking station can drastically change your entire work environment. With one, your hastily cobbled together home office can go from a laptop and a desk to something resembling a.

OEM Docking station
OEM Docking station and laptop

In computing, a docking station or port replicator (hub) or dock provides a simplified way of 'plugging-in' a laptop computer to common peripherals. Because a wide range of dockable devices—from mobile telephones to wireless mice—have different connectors, power signaling, and uses, docks are not standardized and are therefore often designed with a specific type of device in mind.[citation needed] This technology is also used on the Nintendo Switchhybrid video game console.

A dock can allow some laptop computers to become a substitute for a desktop computer, without sacrificing the mobile computing functionality of the machine. Portable computers can dock and undock hot, cold or standby, depending on the capabilities of the system. In a cold dock or undock, one completely shuts the computer down before docking/undocking. In a hot dock or undock, the computer remains running when docked/undocked. Standby docking or undocking, an intermediate style used in some designs, allows the computer to be docked/undocked while powered on, but requires that it be placed into a sleep mode prior to docking/undocking.

Types[edit]

Docking stations can be broadly split up into four basic varieties.

Port replicator/hub[edit]

Port replicators (sometimes referred to as passthroughs) are functionally and logically identical to a bundle of extension cables, except that they are plugged in and unplugged together through the device. Some also include electrical adaptors to change from one pinout to another (e.g., Micro-DVI to normal DVI connector.) Often Bus-Powered and small form factor, they functionally duplicate ports from the device to easily access more of the existing ports like: SD cards, peripherals, audio jacks, etc. as well as external display(s).

Breakout dock/multi-port adapter[edit]

A breakout dock is conceptually a breakout box in the form of a dock. It is an extension to a typical port replicator in that it not only replicates existing ports already on the computer, but also offers additional ports. Modern computers most often accomplish this by using a special, often proprietary, connector that consolidates the signals from many concealed traces from onboard external buses into one connector. As such, the dock can offer a greater number of ports than is physically present on the computer. This allows the basic unit to have fewer physical ports while still allowing users a way to access to the full range of features of its motherboard.

Most companies that produce laptops with such breakout ports also offer simpler adapters that grant access to one or two of the buses consolidated in them at a time.

OEM/proprietary dock[edit]

Compaq LTE Lite laptop with proprietary dock

Similar to a breakout device, some docking stations produce multiple connections from one port, only instead of extracting them from internal chipsets, they create them inside the dock using converters. They are functionally identical to a hub with various converters plugged in. Often using proprietary connections and usually meant to be permanently installed, these self-powered docks are intended for specific models of notebook and would require upgrading at the same time as the notebook. Often, OEM docks contain a wired internet connection, dual displays, and a range of USB and Audio connections.

Universal/third party dock[edit]

Functionally similar to OEM docks, but available in seemingly endless combinations, self-powered non-OEM docks still produce multiple connections from one port, only instead of extracting them from internal chipsets, they create them inside the dock using converters. Typically USB-C or Thunderbolt-3 based, they incorporate a range of converters such as USB display adapters or a full external GPU, audio chipsets, NICs, storage enclosures, modems and memory card readers, or even PCI Express card slots connected through an internal USB hub or PCI Express bridge to give the host computer access to extra connections it did not previously possess.[1] Because they are generally vendor neutral, they often support external device charging, more external monitors, and are more flexible to install. They are often the go-to choice for mixed device offices/workplaces to ease complications in deployments.

Notebook/laptop stands and risers[edit]

Notebook/laptop stands are sometimes incorrectly referred to as docking stations, but seems to be carried through from older technology as they do not connect to the computer in any way. They are an inert accessory designed merely to physically support a computer that is placed on it, typically to raise its screen up to a more ergonomic height, provide cooling, or just to conserve desk space. In 2019 some vendors have launched USB and QI (wireless) charging stands, but they are still independent and do not connect with the notebook.

Docking

Vehicle docks[edit]

Vehicle dock with Dell laptop

Mobile docking stations, also sometimes referred to as vehicle mounts, provide stable platforms for notebook, laptop and tablet operation in vehicles. Many industries have adopted mobile computing and hence operators wish to have their vehicles fully equipped as mobile field-offices, commonly referred to as mobile offices. As of 2015 organizations use mobile docking stations in sectors such as (for example): law-enforcement, electricity, telecommunications, the military, emergency medical services, fire, construction, insurance, real-estate, agriculture, oil, gas, transportation, warehousing, food-distribution, surveying, and landscaping.[2]

Docking Station For Iphone And Watch

Docking station for hp laptop

Docking Station For Hp Elitebook

Some manufacturers design mobile docking stations specially to withstand the rigors of travel; such products may have MIL-STD 810E construction-specifications for vibration and impact.

Mobile docking stations usually come mated to an armature, laptop desk or standard rack in order to provide the ability to position the computer in a vehicle in a safe and ergonomic position. As with all docking stations, a mobile docking station will provide the user with a means to quickly and easily dock and un dock the computer. In addition, some mobile docking-stations provide a security-lock to discourage theft.

Types of vehicle based docking stations[edit]

  • Car Mounts are designed for use with most popular automobiles.
  • Truck Mounts are designed for use with most popular pickup trucks, vans, SUVs and heavy-duty trucks.
  • Cart Mounts and Forklift Mounts are designed to mount notebook, laptop & tablet computers on forklifts and warehouse carts.

Vehicle mount components[edit]

Buku karya buya hamka pdf. Basic components in the design of computer vehicle mounts include:

  • Docking station: The actual station or cradle in which the mobile PC rests. These stations may come equipped with additional functionality, such as charging and USB ports.
  • Motion attachments: Movable components of a mounting system that attach between the pole or tube and the mount base. These come in a number of varieties, allowing the user to configure their mount's range of motion to desired specifications.
  • Mounting base: Attaches the mounting system to the vehicle. This element is commonly composed of rugged materials such as steel. Tunnel Mounts attach to the raised floor area (drive shaft tunnel) between the driver and passenger. Passenger Side Mounts attach to floor on the passenger side of the vehicle. Console mounting brackets attach to an existing vehicle center console. Trunk Mounts provide mounting options for use inside car trunks.
  • Poles and tubes: Attachments that allow the user to adjust the length and particular setup of the mount for the particular vehicle style.

Docking Station For Laptop

Docking systems are shipped in their individual components, requiring the user to install and configure the device. Free diamonds elvenar.

Station

See also[edit]

Wikimedia Commons has media related to Docking stations.

References[edit]

Docking Station For Dell Laptop

  1. ^Nadel, Brian (2020-10-22). 'USB-C explained: How to get the most from it (and why it keeps getting better)'. Computerworld. Retrieved 2020-12-03.
  2. ^'Top 12 Considerations for a Successful Mobile Computing Project, Part 3 | Hendon Publishing'. www.hendonpub.com. Retrieved 2019-07-04.
Retrieved from 'https://en.wikipedia.org/w/index.php?title=Docking_station&oldid=1019810683'

A docking station is a bridge to the past for many newer computers, but users might find that they need one even if they have the latest model. It's a device into which a person can plug a laptop in order to gain extra functionality, such as access to printers, mice, scanners, full-sized monitors and keyboards, and external hard drives. All of these peripherals can be plugged into the dock, and then, when the user connects the laptop, he can gain access to all of those peripherals without having to plug each one into the computer. This can be especially helpful if the laptop has a minimal number of USB or Firewire® ports.

Most newer laptops have more than enough USB or Firewire® ports for casual use, although some users find that they want to access a desktop monitor while using the laptop. Sometimes, a larger keyboard is also easier to type on. In each of these cases, it's usually possible for the user to plug the monitor or the keyboard directly into the laptop. Having everything plugged into a central device can provide more flexibility, however, especially if the laptop is often used on the go.

One instance in which this is particularly useful is when a person wants to hook up a newer laptop to an older printer. Printers of even the recent past routinely have serial port connectors, which are extremely uncommon on most laptops. In this case, it is possible to buy an adapter, but docking stations often include this type of port.

Docking Station For Hp Laptop

In essence, using a docking station converts a laptop computer into a desktop computer, even for a short period of time. A user can plug all of his peripheral devices into this machine so that they're easy to access, and then just unplug the computer itself when on the go, rather than having to disconnect each individual item. Especially when a combination of newer and older technology is used, this often allows everything to work together more easily.
